The LiTHIUMVALLEY SCA261L100P-13W is a commercial-grade energy storage system (BESS) with a total capacity of 250 kWh. It is paired with two Monet-125 AC photovoltaic inverters. It utilizes lithium iron phosphate (LiFePO4) batteries with a cell size of 3.2V and 314Ah. Each battery pack has a capacity of 52.24 kWh. A 1P260S battery pack configuration provides a cycle life of 28,000 cycles (at 25°C, 0.5/0.5P). With a nominal voltage of 832V, an operating voltage of 728-949V, and a rated charge and discharge power of 0.5P, it is suitable for industrial and commercial energy management scenarios.
SMILE5 Series system is the bestseller of AlphaESS. It is available for DC-coupling, AC-coupling and hybrid-coupling connection and working with multiple battery options including 2.9kWh, 5.7kWh, 10.1kWh and 13.3kWh battery module. With VPP value stacked, it would be the best choice for householders.
/
LV-IESS-Hx_RH5.12x 50kWh Indoor rack-mounted installation
Back to products
HS5-5A（High-voltage Stack Battery）
The LiTHIUMVALLEY SCA261L100P-13W is a commercial-grade energy storage system (BESS) with a total capacity of 250 kWh. It is paired with two Monet-125 AC photovoltaic inverters. It utilizes lithium iron phosphate (LiFePO4) batteries with a cell size of 3.2V and 314Ah. Each battery pack has a capacity of 52.24 kWh. A 1P260S battery pack configuration provides a cycle life of 28,000 cycles (at 25°C, 0.5/0.5P). With a nominal voltage of 832V, an operating voltage of 728-949V, and a rated charge and discharge power of 0.5P, it is suitable for industrial and commercial energy management scenarios.
Model
SCA261L100p-13W
Nominal Energy
522kWh
Rated Power
250kw
Nominal Voltage
Operating Voltage
832V
728-949V
Dimensions (WxDxH)
1300×1550 x2090mm
Cycle life
≥8000 cydes(@25°C, 0.5P/0.5P)
IP Rating
IP54
Certifcation
IEC/EN 61000,IEC 62619,UN38.3, MSDS
FEATURES
Total Capacity & Inverters
250kWh commercial-grade energy storage system (BESS), paired with two Monet-125 AC photovoltaic inverters
Battery Configuration
Uses lithium iron phosphate (LiFePO₄) batteries (3.2V/314Ah), with each battery pack at 52.24kWh.
Cycle Life
IP260S configuration enables 28,000 cycles (at 25°C, 0.5P/0.5P).
Electrical Performance
Nominal voltage 832V, operating voltage 728–949V, fits 0.5P charge/discharge scenarios.
Protection & Dimensions
IP54 rating; dimensions: 1300×1550×2090mm (W×D×H).
Certifications & Scenarios
Complies with IEC/EN 61000, UN38.3, etc.; suitable for industrial and commercial energy management.
